Southern Cross Injector Nozzle - BDN40S2
SKU: BDN40S2
A superb quality Italian made DN40S2 nozzle suitable for the following Southern Cross engines when set to the correct pressure (Listed Below) YB, ETB, BDC, BEC, BFC, BCC, GEC, GFC, GGC, GFC, YC & YDB.
Pressure Settings (Atmospheres or Pounds Per Square Inch)
- Southern Cross YB 4HP: 115ATS or 1690PSI
- Southern Cross ETB 2.5 HP: 100ATS or 1470PSI
- Southern Cross ET 4HP: 100ATS or 1470PSI
- Southern Cross BDC 1200 RPM 10HP: 100ATS or 1470PSI
- Southern Cross BDC 1500 RPM 12.5HP: 75ATS or 1102PSI
- Southern Cross BEC 1200 RPM 20HP: 100ATS or1470PSI
- Southern Cross BFC 1200 RPM 30HP: 100ATS or1470PSI
- Southern Cross BCC 1200 RPM 40HP: 100ATS or 1470PSI
- Southern Cross GEC 1200 RPM 20HP: 100ATS or 1470PSI
- Southern Cross GFC 1200 RPM 30HP 100ATS or 1470PSI
- Southern Cross GGC 1200 RPM 40HP: 100ATS or 1470PSI
- Southern Cross GGC 1500 RPM 50HP: 75ATS or 1102PSI
- Southern Cross GFC 1500 RPM 37.5 HP: 75ATS or 1102PSI
- Southern Cross GGC 1500 RPM 50HP: 75ATS or 1102PSI
- Southern Cross YC 9.7HP: 115ATS or 1690PSI
- Southern Cross YDB 10.8HP: 110ATS or 1616PSI
Nozzle Type: Pintle
Equivalent Part Numbers
The following is a cross reference of equivalent part numbers for various other brands of this nozzle.
- BOSCH: 0.434.200.025
- BRYCE: P2S40
- DELPHI: 5642016
- DELPHI: BDN40S2
- ROBERT BOSCH: DN40S2
- SIMMS: N40S2
- DENSO: 105000-0330
