Lister CS 8/1 Aluminium Piston Assembly P/N 574-10350
Lister CS aluminium piston assemblies suitable for 8/1 and 16/2 genuine Lister engines. These high-quality aftermarket piston assemblies are available in Standard (STD) to suit 4.5" bore, and 0.020”, 0.040” & 0.060” oversize, please select size required when ordering.
The piston set comes complete with a set of high quality piston rings that uses a chrome plated top ring for longer life and wear resistance, a gudgeon pin an pair of new cir-clips. The assembly is equivalent to Lister Petter part numbers: 574-10350, 574-10350/020, 574-10350/040, 574-10350/060.
Important Note: This set is not suitable for chrome plated cylinder bores due to the top ring being chrome, if you need to use this assembly in a chrome bore the top ring will need to be replaced with a standard cast iron top tapered ring (key stone ring). These are available on request, subject to availability.
What’s included:
- 1 x 4 ring aluminium piston
- 1 x piston ring set (chrome plated tapered top ring)
- 1 x gudgeon pin
- 2 x cir-clips
