Lister JP, JK, JS

CAV, Bryce, Pyrox type 7mm fuel pump element (Plunger & Barrel) suitable for the B size BPF and PF fuel injector pumps. This new high quality Italian made element will fit the Lister CS 5/1, 6/1, 8/1, 10/2, 12/2, 16/2, VA, JP, CD & CE.

Fuel pump element (Plunger & Barrel) suitable for JP616 & JK diesel engines. This is 7010-562Q element is equivalent to Lister Petter part number 660-11120.

Genuine Lister exhaust valve for JP616 & JK6 diesel engines, lister part number 614-00832.

Genuine Lister inlet valve for JP616 & JK6 diesel engines, lister part number 614-00831.

Injector washer suitable for Lister CS, 9/1, JP, CD & CE, equivalent to Lister part number 010-03041.

Sold Individually.

Genuine CAV fuel pump delivery valve holder suitable for CAV, PYROX, Bryce & Bosch PF1B, BPF1B, fuel injector pumps with element sizes from 5mm to 8mm. CAV part number 7010-479.

Genuine CAV BPE-B fuel injector pump dipstick, used on a wide range of vintage engines including the Lister JP2 JP3 & JP4. CAV part number 7010-326.

Genuine CAV BPE-B fuel injector pump fibre coupling disc, used on a wide range of multi cylinder vintage engines including the Lister JP2 JP3, JP4, JK & JS. CAV part number 7021-129A, Lister 660-10080.

Genuine CAV fuel injector leak off connection suitable for original CAV injectors fitted to Lister CS, JP, CD & CE. CAV part number 7008-3, Lister 660-10760.

Genuine new old stock connecting rod bush (Small End) for Lister JP, 9/1, JK, JS & 616 diesel engines. Lister part number 010-04007/019 and supersedes 010-04007, 10-4-8, 8-1/D7S, 10-4-7S & 8-1/D7.

Genuine new old stock 0.004” head gasket shim for Lister 9/1, JP, JS & JK water cooled diesel engines, suitable for 1, 2, 3 & 4 cylinder engines only. Lister part number 010-03179, supersedes 10-3-179.

Sold Individually.

Genuine Lister 9-1, JP2, JP3 & JP4 cylinder head (Rover Cover) gasket, part number 011-03291, supersedes 11-3-291.

Exhaust manifold joint (Manifold to Cylinder Head), suitable for JP616 & JK6 water cooled diesel engines. A well-made reproduction gasket equivalent to Lister part number 614-719.

Genuine Lister JP crankcase door joint (small), suitable for JP1 (9/1), JP2, JP3 & JP4. Lister part number 010-02061, supersedes 10-2-61, 10-2-61A, 10-2-61-1, 8-1/B61A. This gasket suits the small door only, measures approximately 9-1/2” x 7-3/4”.

Genuine Lister water pump distance piece, suitable for pumps fitted on Lister FR, JP, JW, HRW and HW engines.

Lister part number 291-30350.

Genuine Lister JP, JS & JK cylinder liner rubber sealing ring. Sold individually, normally you will find 4 rubber sealing rings on each genuine liner, aftermarket liners may only have 3. Lister part number 010-02116, supersedes 10-2-116 & 8-1/B116.

Genuine Lister JP2, JP3 & JP4 lubricating oil pump cast joint, part number 010-02112.

Genuine new old stock replacement fuel filter wick, complete with nipple and clamp, for Lister CS 3/1, 3.5/1, 5/1, 6/1, 8/1, 10/2, 12/2, JP, JK, CE & CD diesel engines fitted with the original standard cast iron fuel filters, part number 023-02288, replaces 23/22880, 23-2288, 575-10190.

A high-quality reprint Lister JP, JS & JK instructions, basic workshop manual and detailed parts list. Covering 1, 2 & 3 cylinder LD & SL diesel engines, loaded with valuable information including torque settings and clearances, this 106 page manual is a must have for anyone owing or rebuilding one of these engines.

Complete non-genuine piston and liner set suitable for Lister JP, JK & JS engines. The set includes piston, rings, gudgeon pin & clips, new liner and sealing rings. Equivalent to Lister part numbers 010-02247 and 573-10430.

A non-genuine piston assembly to suit the Lister 9-1, JP, JK & JS range of diesel engines. The assembly includes piston, rings, gudgeon pin, and clips. Suitable for 1, 2, 3, 4, & 6 cylinder engines with cast iron liners. Please note that this assembly is not suitable for chrome liners without first changing the top chrome ring to a plain ring.

New non-genuine cylinder liners to the Lister JP, JK & JS range of engines, equivalent to Lister part number 010-02247. Comes complete the 3 sealing rubbers.

These non-genuine high quality piston ring sets are suitable for all 9/1, JP, JS & JK engines with a 4 ring alloy piston and a non-chrome cylinder liner. Note: These ring sets are suitable for use with genuine Lister Aluminium pistons, but are only compatible with non-chrome plated cylinders, the top piston ring is chrome plated for use in an unchromed liner only.

These non-genuine high quality piston ring sets are suitable for all 9/1, JP, JS & JK engines with a 4 ring alloy piston and a chrome plated cylinder liner. Note: These rings are suitable for use with genuine Lister Aluminium pistons, and compatible with chrome plated cylinder liners.

Lister JP centre bearing, genuine New Old Stock, only available in STD. Suitable for JP, JK & JS 3 & 4 cylinder engines. 3 cylinder engine require 2 sets, and 4 cylinder engine require 1 set.

For reference please see Part No11 in picture.

Valve spring carrier and cone/collets suitable for a wide range of vintage Lister diesel engines, including all the CS 3-1, 3.5-1, 5-1, 6-1, 8-1, 10-2, 12-2 & 16-2 range, as well as the VA, CD, CE and JP’s. This aftermarket set includes 6 parts in total, 2 valve spring carriers (010-03130) and 2 (pair) cone/cotters (010-00325).

Sold in pairs as shown in photo.

Full set of 4 non-genuine valve springs suitable for all the Lister CS range of diesel engines, these spring sets will also fit the Lister JP’s and CD/CE engines. Included are 2 x inner valve springs equivalent to Lister part numbers 11-3-219 or 012-03219, and 2 x outer valve spring equivalent to Lister part numbers 10-3-129 or 012-03129.

These aftermarket precision ground Lister JP inlet valve made from EN52 grade steel as per original specification.

Equivalent Lister part numbers: 10-3-8A, 010-03008.

These aftermarket precision ground Lister JP exhaust valve made from EN52 grade steel as per original specification.

Equivalent Lister part numbers: 10-3-121, 010-03121.

Genuine new old stock Lister JP, JK & JS valve push rods. These are the early style as pictured but will fit the later JP engines as the length is the same. The length is approximately 12.75”.

Superb quality Bryce, CAV, Delphi, Bosch, or equivalent injector nozzle suitable for Lister JP1, JP2, JP3, JP4, JP6 & JPM models, also suitable for JK2, JK3, JK4 & JK6 models. This BDL30S54 nozzle is equivalent to Lister Part Number 616-02145.

Genuine new old stock Lister 'O' Ring 010-03038, used on CS and JP engine for the rubber injector sealing O-ring, these are only required if you have an early CS or JP with the water cooled injector (See Notes). Also used on Lister HA, HB, HR 4 & 6 cylinder engines in the axial flow cooling fan assembly as a sealing O-Ring.

Brand new genuine Bosch fuel injector, modern equivalent suitable for Lister JP1, JP2, JP3 & JP4 cold start diesel engines. This high quality injector assembly comes complete with a BDL30S54 injector nozzle set to 150 ATS and a copper sealing washer. May not be suitable for some early engines, see below for more details…

New replacement old type fuel filter wick for all original Lister diesel engines fitted with this style of fuel filter. This quality aftermarket fuel filter wick complete with nipple and clamp is suitable for use in the original standard cast iron fuel filters found on Lister CS, JP, JK, FR, CE & CD engines.

 Equivalent to Lister part numbers: 023-02288, 23-2288

Fuel pump delivery valve for the Lister JA6 P/N 1/367X.

A very high quality made non asbestos copper laminated gasket for the exhaust flange and inlet joint on all Lister CS & JP diesel engines and the exhaust flange side of early Lister J, K, L & M petrol/paraffin engines.

Lister JP cylinder head gasket, made from copper and non-asbestos composite, equivalent to Lister P/N 8-1/C105 or 010-03105. These high quality aftermarket gaskets are suitable for 9/1, JP, JP2, JP3 & JP4.

Genuine Lister centrifugal water pump carbon driver, suitable for pumps fitted on Lister FR, JP, JW, HRW and HW engines.

Lister part number 291-38850.
